Product Center
Poly01 Thermopile
Module
Our flagship thermopile module delivers high-precision thermal sensing in an ultra-compact form factor, designed for both automotive and consumer applications.
Poly01
<100mK
NETD
32×24
Resolution
120Hz
Frame Rate
20×20mm
Size
IP52
Protection
USB/UART
Interface
Sensor Parameters
Sensor Type
Thermopile
Resolution
32 × 24
Pixel Size
< 150μm
Frame Rate
120Hz
Spectral Range
8 ~ 14μm
NETD
< 100mK RMS @1Hz
Module Features
Temperature Accuracy
±2°C (0~2m)
Dimensions
20mm (L) × 20mm (W)
Ingress Protection
IP52
Operating Temp
-40°C ~ 85°C
Storage Temp
-40°C ~ 95°C
Electrical Specifications
Supply Voltage
DC 5V
Communication Ports
USB / UART / LIN2.X
Field of View
75° × 35°
Applications
Application Scenarios
01
Automotive
- Smart cabin climate control
- Driver monitoring system
- Occupant detection
- Autonomous driving assistance
02
Consumer
- Smart home automation
- Health monitoring devices
- Security systems
- Energy management
03
Industrial
- Process monitoring
- Equipment inspection
- Safety systems
- Building automation
Request a Sample
Interested in evaluating the Poly01 module for your project? Contact us for samples and technical documentation.
Request Sample
